Frame
28", super lite AL-6061 tubing, PowerTube battery
-
Fork
Suntour NVX32 NLO DS, 100 mm
-
Drive unit
Bosch Smart System, Performance Line PX (BDU347Y), 250 W, 36 V, max. 25 km/h
-
Battery
Bosch PowerTube, 36 V Li Ion, 600 Wh
-
Display
Bosch Intuvia 100 with LED Remote
-
Charger
Bosch Smart System, 2 A
-
Shifters
Shimano Nexus, SL-C7000, 5-speed, revo-shifter
-
Crankset
Miranda Virage, 170 mm, belt, 46t
-
BB-Set
Bosch, Isis
-
Chain
Gates CDX Carbon Drive Belt, Center-Track
-
Cassette
Gates CDX, 32t
-
Brake levers
Shimano BL-MT200, hydraulic disc brake
-
Brakes
Shimano BR-MT200, hydraulic disc brake
-
Rotor
Shimano SM-RT10, 180 mm
-
Handlebar
Syncros 3.0, riserbar, backsweep: 40°, rise: 40 mm
-
H'stem
Syncros, with SP Connect mount, adjustable
-
Seatpost
Syncros
-
Seat
Syncros Capilano City
-
Headset
Acros, A-Headset, semi-integrated, tapered, with integrated cable routing
-
Front hub
Shimano HB-QC400, centerlock, disc, quick release
-
Rear hub
Shimano Nexus, SG-C7000-5, freehub, centerlock, disc
-
Spokes
Stainless, black
-
Rims
Syncros X17, disc, eyelets
-
Front tire
Schwalbe Energizer Plus Tour, Performance, Greenguard, reflective stripe, 55-622 Tube: Schwalbe AV19B Light
-
Rear tire
Schwalbe Energizer Plus Tour, Performance, Greenguard, reflective stripe, 55-622 Tube: Schwalbe AV19B Light
-
Lights
Front: Lezyne Mini E300, 100 Lux, LED, Rear: LED, with brake light function
-
Rack
Racktime / BGM Trekking Pro, Snapit 2.0 System
-
Pedals
Marwi SP-827, sandblock
-
Accessories
Kickstand: Syncros U-mount
-
Approx weight in KG
30,8
-
Fender
Curana Apollo, with stainless stays
-
Grips
Syncros Urban, Ergo, double density, lock-on
-
Max. system weight
130,0 kg (The overall weight includes the bike, the rider, the equipment and possible additional luggage.)
-
Geometry S
A: 440 mm (17,3 in), B*: 575 mm (22,6 in), C: 495 mm (19,5 in), D: 160 mm (6,3 in), E: 67,0 °, F: 76,0 °, H: 63 mm (2,5 in), K: 1.214 mm (47,8 in), L: 448 mm (17,6 in), M: 696 mm (27,4 in), N: 399 mm (15,7 in), Fork length: 547 mm (21,5 in), Fork rake: 51 mm (2,0 in)
-
Geometry M
A: 480 mm (18,9 in), B*: 595 mm (23,4 in), C: 495 mm (19,5 in), D: 160 mm (6,3 in), E: 67,0 °, F: 76,0 °, H: 63 mm (2,5 in), K: 1.234 mm (48,6 in), L: 448 mm (17,6 in), M: 696 mm (27,4 in), N: 419 mm (16,5 in), Fork length: 547 mm (21,5 in), Fork rake: 51 mm (2,0 in)
-
Geometry L
A: 520 mm (20,5 in), B*: 615 mm (24,2 in), C: 495 mm (19,5 in), D: 170 mm (6,7 in), E: 67,0 °, F: 76,0 °, H: 63 mm (2,5 in), K: 1.256 mm (49,4 in), L: 448 mm (17,6 in), M: 705 mm (27,8 in), N: 437 mm (17,2 in), Fork length: 547 mm (21,5 in), Fork rake: 51 mm (2,0 in)
-
Geometry XL
A: 560 mm (22,0 in), B*: 615 mm (24,2 in), C: 495 mm (19,5 in), D: 170 mm (6,7 in), E: 67,0 °, F: 76,0 °, H: 63 mm (2,5 in), K: 1.256 mm (49,4 in), L: 448 mm (17,6 in), M: 705 mm (27,8 in), N: 437 mm (17,2 in), Fork length: 547 mm (21,5 in), Fork rake: 51 mm (2,0 in)
-
Seatpost diameter
31,6 mm
-
Headset dimension
ZS56/ZS56
-
BB standard
Bosch
-
Hanger type
BGM-H058CD
-
Max. rotor size
180 mm
-
Technology
Child Seat Allowed (Please refer to the chapter "intended use of your bike" in the general manual for details.)
