Frame
28", lite investment casting, ultra lite AL-6061 tubing, CompactTube battery
-
Fork
Suntour NRX32-E-Air LOR DS, 75 mm, 15x100 mm axle
-
Drive unit
Bosch Performance Line SX, 250 W, 36 V, max. 25 km/h
-
Battery
Bosch CompactTube, 36 V Li Ion, 400 Wh
-
Display
Bosch Intuvia 100 with LED Remote
-
Charger
Bosch Compact Charger, 2A
-
Shifters
Shimano Nexus, SL-C7000, 5-speed, revo-shifter
-
Crankset
FSA CK-220, 170 mm, belt, 52t
-
BB-Set
Bosch, Isis
-
Chain
Gates CDC Carbon Drive Belt, Center-Track
-
Cassette
Gates CDC, 34t
-
Brake levers
Shimano BL-MT200, hydraulic disc brake
-
Brakes
Shimano BR-MT200, hydraulic disc brake
-
Rotor
Shimano SM-RT10, 180 mm
-
Grips
Syncros Urban, Ergo, double density, lock-on
-
Handlebar
BGM Pro, riserbar, backsweep: 40°, rise: 40 mm
-
H'stem
Satori Rana, 20°
-
Seatpost
BGM Pro
-
Seat
Syncros Capilano City
-
Headset
Acros, A-Headset, semi-integrated, 1.5", with integrated cable routing
-
Front hub
Shimano HB-TC500, centerlock, disc, 15x100 mm axle
-
Rear hub
Shimano Nexus, SG-C7000-5, freehub, centerlock, disc
-
Spokes
stainless, black
-
Rims
BGM Pro X15, disc, eyelets
-
Front tire
Schwalbe Marathon Efficiency, Performance, RaceGuard, reflective stripe, 55-622Tube: Schwalbe SV19B Light
-
Rear tire
Schwalbe Marathon Efficiency, Performance, RaceGuard, reflective stripe, 55-622Tube: Schwalbe SV19B Light
-
Lights
Front: Trelock LS830, 80 Lux, LED; Rear: Axa Juno, LED, with brake light function
-
Rack
Racktime / BGM E-Ville carrier, Snapit 2.0 System
-
Fender
Curana C-Lite, with stainless stays
-
Pedals
Marwi SP-827, sandblock
-
Accessories
Kickstand: Syncros U-mount
-
Approx weight in kg
24,2
-
Max. system weight
130,0 kg (The overall weight includes the bike, the rider, the equipment and possible additional luggage.)
