Frame
29", super lite AL-6061 tubing, BES III, PowerTube battery
Fork
Suntour XCR34 LOR, 120 mm, rebound adjust, 15x110 mm axle
Drive unit
Bosch Performance Line CX, Gen. 4, BES3, 250 W, 36 V, max. 25 km/h
Battery
Bosch PowerTube, 36 V Li Ion, 625 Wh
Display
Bosch LED Remote with Kiox 300 display
Charger
Bosch Standard Charger, 4A
Rear derailleur
Shimano Deore, RD-M5100, Shadow Plus
Shifters
Shimano Deore, SL-M5100, 1x11-speed, rapidfire plus-shifter
Crankset
FSA CK-320, 34t, 170 mm
BB-set
Bosch, Isis
Chain
KMC e11S
Cassette
Shimano Deore, CS-M5100, 11-51t
Brake levers
Shimano BL-M4100, hydraulic disc brake
Brakes
Shimano BR-MT410, hydraulic disc brake
Rotor
Front: 203 mm, Rear: 180 mm
Grips
Syncros E-MTB
Handlebar
Syncros Hixon 2.0, mini riserbar, rise: 15 mm, width: 740 mm
Stem
Satori Viper, 0°
Seatpost
Syncros M3.0
Seat
Syncros Savona 2.5
Headset
Acros, A-Headset, semi-integrated, 1.5", with integrated cable routing, with block lock
Front hub
Shimano HB-MT400-B, centerlock, disc, 15x110 mm axle
Rear hub
Shimano FH-MT400-B, centerlock, disc, 12x148 mm axle
Spokes
Stainless, black
Rims
Cross X18, disc, eyelets, width: 30 mm
Tires
Schwalbe Al Grounder, 29x2.35"
Lights
Front: Litemove SE, 110 Lux, LED; Rear: Herrmans H-Trace Mini, LED
Rack
Racktime / BGM E-revox carrier, SnapIt 2.0 System
Fender
Curana Apollo, with stainless stays
Pedals
MTB alloy
Accessories
Kickstand: Syncros
Weight
27.2 kg
Max. system weight
135.0 kg
Seatpost diameter
31.6 mm
Headset dimension
ZS56/ZS56
BB standard
Bosch Gen4 / Bosch Gen3
Hanger type
BGM-H054
Max. rotor size
220 mm
