Frame
29", super lite AL-6061 tubing, BES III, PowerTube battery
-
Fork
Suntour XCR34 LOR, 120 mm, rebound adjust, 15x110 mm axle
-
Drive unit
Bosch Performance Line CX, Gen. 4, BES3, 250 W, 36 V, max. 25 km/h
-
Battery
Bosch PowerTube, 36 V Li Ion, 750 Wh
-
Display
Bosch LED Remote with Kiox 300 display
-
Charger
Bosch Standard Charger, 4A
-
Rear derailleur
Shimano Deore, RD-M5100, Shadow Plus
-
Shifters
Shimano Deore, SL-M5100, 1x11-speed, rapidfire plus-shifter
-
Crankset
FSA CK-320, 34t, 170 mm
-
BB-Set
Bosch, Isis
-
Chain
KMC e11S
-
Cassette
Shimano Deore, CS-M5100, 11-51t
-
Brake levers
Shimano BL-M4100, hydraulic disc brake
-
Brakes
Shimano BR-MT410, hydraulic disc brake
-
Rotor
Front: Shimano SM-RT30, 203 mm
Rear: Shimano SM-RT30, 180 mm
-
Grips
Syncros E-MTB
-
Handlebar
Syncros Hixon 2.0, mini riserbar, rise: 15 mm, width: 740 mm
-
H'stem
Satori Viper, 0
-
Seatpost
Syncros M3.0
-
Seat
Syncros Savona 2.5
-
Headset
Acros, A-Headset, semi-integrated, 1.5", with integrated cable routing, with block lock
-
Front hub
Shimano HB-MT400-B, centerlock, disc, 15x110 mm axle
-
Rear hub
Shimano FH-MT400-B, centerlock, disc, 12x148 mm axle
-
Spokes
stainless, black
-
Rims
Cross X18, disc, eyelets, width: 30 mm
-
Front tire
Schwalbe Nobby Nic Evo, Super Trail, Tubeless-Easy, 29x2.60"
Tube: Schwalbe SV19FB Light
-
Rear tire
Schwalbe Nobby Nic Evo, Super Trail, Tubeless-Easy, 29x2.60"
Tube: Schwalbe SV19FB Light
-
Pedals
MTB alloy
-
Accessories
Kickstand: Syncros
-
Approx weight in kg
27,3
-
Color
shiny mulberry red
-
Frame size
S/M/L
-
Max. system weight
135,0 kg
The overall weight includes the bike, the rider, the equipment and possible additional luggage.
