Frame
28", super lite AL-6061 tubing, BES III, PowerTube battery
Fork
Suntour Mobie 25 DS RLR, 100 mm, 15x100 mm axle
Drive unit
Bosch Performance Line CX, Gen. 4, BES3, 250 W, 36 V, max. 25 km/h
Battery
Bosch PowerTube, 36 V Li Ion, 750 Wh
Display
Bosch LED Remote with Kiox 300
Charger
Bosch Standard Charger, 4A
Rear derailleur
Shimano Deore XT, RD-M8130, Shadow Plus
Shifters
Shimano Deore XT, SL-M8130, 1x11-speed, rapidfire plus-shifter
Crankset
FSA CK-745, 38t
BB-set
Bosch, Isis
BB standard
Bosch Gen4
Chain
Shimano Linkglide, CN-LG500
Cassette
Shimano Linkglide, CS-LG700-11, 11-50t
Brakes
Tektro HD-M745, hydraulic disc brake, 4-piston
Rotor
Tektro TR180-35, 180 mm
Max. rotor size
220 mm
Grips
BGM Comfort, Ergo, double density, lock-on
Handlebar
BGM Pro, riserbar, backsweep: 15°, rise: 5 mm
Stem
Satori Python, adjustable
Seatpost
Syncros Duncan, dropper post, 120 mm travel, remote
Seatpost diameter
31.6 mm
Seat
Syncros Capilano Trekking Gel
Headset
Acros, A-Headset, semi-integrated, tapered, with integrated cable routing
Headset dimension
ZS56/ZS56
Front hub
Shimano HB-TC500, centerlock, disc, 15x100 mm axle
Rear hub
Shimano FH-UR600 centerlock, disc, quick release
Spokes
Sapim Leader
Rims
Ryde Rival 23 disc, eyelets
Tires
Schwalbe Marathon Plus MTB, Smart Dual Guard, reflective stripe, 54-622
Lights
Front: B&M IQ XS, 150 Lux (high beam), LED; Rear: B&M Toplight Line brex, LED, with brake light
Rack
Racktime / BGM Trekking Pro, Snapit 2.0 System, integrated fender mount
Fender
Racktime Alumee
Pedals
Trekking alloy, platform
Accessories
Kickstand: Syncros
Weight
28.9 kg
Maximum system weight
160.0 kg
Chain cover
Integrated in motor cover
